General information
BrandVolvo
Model XC40
Generation XC40 (facelift 2022)
Modification (Engine) 1.5 T2 (129 Hp)
Start of production March, 2022 year
Powertrain Architecture Internal Combustion engine
Body typeSUV
Seats 5
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 8.9-9.6 l/100 km 26.43 - 24.5 US mpg31.74 - 29.43 UK mpg11.24 - 10.42 km/l
Fuel consumption at Medium speed (WLTP) 6.7-7.4 l/100 km 35.11 - 31.79 US mpg42.16 - 38.17 UK mpg14.93 - 13.51 km/l
Fuel consumption at high speed (WLTP) 5.9-6.6 l/100 km 39.87 - 35.64 US mpg47.88 - 42.8 UK mpg16.95 - 15.15 km/l
Fuel consumption at very high speed (WLTP) 7.2-8 l/100 km 32.67 - 29.4 US mpg39.23 - 35.31 UK mpg13.89 - 12.5 km/l
Combined fuel consumption (WLTP) 7-7.6 l/100 km 33.6 - 30.95 US mpg40.35 - 37.17 UK mpg14.29 - 13.16 km/l
CO2 emissions (WLTP)158-173 g/km
Fuel consumption (economy) - combined (NEDC, WLTP equivalent) 6.3-6.4 l/100 km 37.34 - 36.75 US mpg44.84 - 44.14 UK mpg15.87 - 15.63 km/l
CO2 emissions (NEDC, WLTP equivalent)142-146 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h10.9 sec
Acceleration 0 - 62 mph10.9 sec
Acceleration 0 - 60 mph 10.4 sec
Maximum speed 180 km/h, Electronically limited 111.85 mph
100 km/h - 0 36 m
Emission standard Euro 6d
Engine specs
Power 129 Hp @ 5000 rpm.
Power per litre 87.3 Hp/l
Torque 245 Nm 180.7 lb.-ft.
Maximum engine speed 6000 rpm.
Engine location Front, Transverse
Engine Model/Code B3154T9
Engine displacement 1477 cm3 90.13 cu. in.
Number of cylinders 3
Position of cylinders Inline
Cylinder Bore 82 mm 3.23 in.
Piston Stroke 93.2 mm 3.67 in.
Compression ratio 10.5
Number of valves per cylinder 4
Fuel System Direct injection
Engine aspiration Turbocharger
Valvetrain DOHC
Engine oil capacity 5.6 l 5.92 US qt | 4.93 UK qt
Oil viscosity No Data
Engine oil specification
Engine systemsStart & Stop SystemParticulate filter
Space, Volume and weights
Trunk (boot) space - minimum 452 l 15.96 cu. ft.
Trunk (boot) space - maximum 1328 l 46.9 cu. ft.
Fuel tank capacity 54 l 14.27 US gal | 11.88 UK gal
Max. roof load 75 kg 165.35 lbs.
Permitted trailer load with brakes (12%) 1600 kg 3527.4 lbs.
Permitted trailer load without brakes 750 kg 1653.47 lbs.
Dimensions
Length 4425 mm 174.21 in.
Width 1863 mm 73.35 in.
Width with mirrors folded 1910 mm 75.2 in.
Width including mirrors 2034 mm 80.08 in.
Height 1652 mm 65.04 in.
Wheelbase 2702 mm 106.38 in.
Front track 1601 mm 63.03 in.
Rear (Back) track 1626 mm 64.02 in.
Front overhang 855 mm 33.66 in.
Rear overhang 868 mm 34.17 in.
Ride height (ground clearance) 196 mm 7.72 in.
Drag coefficient (Cd) 0.340
Minimum turning circle (turning diameter) 11.8 m 38.71 ft.
Approach angle 20.3°
Departure angle 26.9°
Ramp-over (brakeover) angle 20.3°
Wading depth 450 mm 17.72 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of Gears (manual transmission) 6
Front suspension Independent, Spring McPherson, with stabilizer
Rear suspension Independent, spring multi-link with stabilizer
Front brakesVentilated discs, 296-345x25-30 mm
Rear brakesVentilated discs, 280-340x12-20 mm
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Wheel rims size16; 17; 18
