General information
BrandVolvo
Model V70
Generation V70 II (facelift 2004)
Modification (Engine) 2.0T (180 Hp)
Start of production 2004 year
End of production 2007 year
Powertrain Architecture Internal Combustion engine
Body typeStation wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) - urban (NEDC) 12.7 l/100 km 18.52 US mpg22.24 UK mpg7.87 km/l
Fuel consumption (economy) - extra urban (NEDC) 7 l/100 km 33.6 US mpg40.35 UK mpg14.29 km/l
Fuel consumption (economy) - combined (NEDC) 9.1 l/100 km 25.85 US mpg31.04 UK mpg10.99 km/l
CO2 emissions (NEDC)217 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h9.1 sec
Acceleration 0 - 62 mph9.1 sec
Acceleration 0 - 60 mph 8.6 sec
Maximum speed 220 km/h 136.7 mph
Emission standard Euro 4
Weight-to-power ratio 8.8 kg/Hp, 113.6 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 151.5 Nm/tonne
Engine specs
Power 180 Hp @ 5500 rpm.
Power per litre 90.7 Hp/l
Torque 240 Nm @ 1850-5000 rpm. 177.01 lb.-ft. @ 1850-5000 rpm.
Engine location Front, Transverse
Engine Model/Code B5204T5
Engine displacement 1984 cm3 121.07 cu. in.
Number of cylinders 5
Position of cylinders Inline
Cylinder Bore 81 mm 3.19 in.
Piston Stroke 77 mm 3.03 in.
Number of valves per cylinder 4
Fuel System Multi-point indirect injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.5-5.8 l 5.81 - 6.13 US qt | 4.84 - 5.1 UK qt
Oil viscosity No Data
Engine oil specification
Coolant 8.8 l 9.3 US qt | 7.74 UK qt
Space, Volume and weights
Kerb Weight 1584 kg 3492.12 lbs.
Max. weight 2130 kg 4695.85 lbs.
Max load 546 kg 1203.72 lbs.
Trunk (boot) space - minimum 485 l 17.13 cu. ft.
Trunk (boot) space - maximum 1641 l 57.95 cu. ft.
Fuel tank capacity 70 l 18.49 US gal | 15.4 UK gal
Max. roof load 100 kg 220.46 lbs.
Permitted trailer load with brakes (12%) 1800 kg 3968.32 lbs.
Permitted trailer load without brakes 750 kg 1653.47 lbs.
Permitted towbar download 75 kg 165.35 lbs.
Dimensions
Length 4710 mm 185.43 in.
Width 1804 mm 71.02 in.
Height 1465 mm 57.68 in.
Wheelbase 2755 mm 108.46 in.
Front track 1551 mm 61.06 in.
Rear (Back) track 1548 mm 60.94 in.
Minimum turning circle (turning diameter) 11.9 m 39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of Gears (manual transmission) 5
Front suspension McPherson, Transverse stabilizer
Rear suspension Transverse stabilizer, Independent multi-link
Front brakesVentilated discs
Rear brakesDisc
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/55 R16
Wheel rims size7J x 16
