General information
BrandTVR
Model Griffith
Generation Griffith
Modification (Engine) 4.0 (240 Hp)
Start of production 1990 year
End of production 1993 year
Powertrain Architecture Internal Combustion engine
Body typeCabriolet
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) - urban 17 l/100 km 13.84 US mpg16.62 UK mpg5.88 km/l
Fuel consumption (economy) - extra urban 10 l/100 km 23.52 US mpg28.25 UK mpg10 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h4.7 sec
Acceleration 0 - 62 mph4.7 sec
Acceleration 0 - 60 mph 4.5 sec
Maximum speed 243 km/h 150.99 mph
Weight-to-power ratio 4.2 kg/Hp, 240 Hp/tonne
Weight-to-torque ratio 2.7 kg/Nm, 366 Nm/tonne
Engine specs
Power 240 Hp @ 5250 rpm.
Power per litre 60.8 Hp/l
Torque 366 Nm @ 3500 rpm. 269.95 lb.-ft. @ 3500 rpm.
Engine location Front, Longitudinal
Engine displacement 3950 cm3 241.04 cu. in.
Number of cylinders 8
Position of cylinders V-engine
Cylinder Bore 94 mm 3.7 in.
Piston Stroke 71.1 mm 2.8 in.
Compression ratio 10.5
Number of valves per cylinder 2
Fuel System Multi-point indirect injection
Engine aspiration Naturally aspirated engine
Space, Volume and weights
Kerb Weight 1000 kg 2204.62 lbs.
Max. weight 1200 kg 2645.55 lbs.
Max load 200 kg 440.92 lbs.
Fuel tank capacity 57 l 15.06 US gal | 12.54 UK gal
Dimensions
Length 3965 mm 156.1 in.
Width 1800 mm 70.87 in.
Height 1200 mm 47.24 in.
Wheelbase 2285 mm 89.96 in.
Front track 1460 mm 57.48 in.
Rear (Back) track 1460 mm 57.48 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of Gears (manual transmission) 5
Front suspension Double wishbone
Rear suspension Double wishbone
Front brakesVentilated discs
Rear brakesVentilated discs
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16; 225/50 R16
