| General information |
|---|
| Brand | Renault |
|---|
| Model | Modus |
|---|
| Generation | Grand Modus (Phase II, 2008) |
|---|
| Modification (Engine) | 1.2 16V (75 Hp) |
|---|
| Start of production | 2008 year |
|---|
| End of production | 2012 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Hatchback |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
7.6 l/100 km
30.95 US mpg37.17 UK mpg13.16 km/l |
| Fuel consumption (economy) - extra urban |
4.9 l/100 km
48 US mpg57.65 UK mpg20.41 km/l |
| Fuel consumption (economy) - combined |
5.9 l/100 km
39.87 US mpg47.88 UK mpg16.95 km/l |
| CO2 emissions | 140 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 13.7 sec |
|---|
| Acceleration 0 - 62 mph | 13.7 sec |
|---|
| Acceleration 0 - 60 mph | 13 sec |
|---|
| Maximum speed |
163 km/h
101.28 mph |
| Emission standard | Euro 4 |
|---|
| Weight-to-power ratio | 15.3 kg/Hp, 65.2 Hp/tonne |
|---|
| Weight-to-torque ratio | 11 kg/Nm, 91.3 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 75 Hp @ 5500 rpm. |
|---|
| Power per litre | 65.3 Hp/l |
|---|
| Torque |
105 Nm @ 4250 rpm.
77.44 lb.-ft. @ 4250 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | D4F |
|---|
| Engine displacement |
1149 cm3
70.12 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
69 mm
2.72 in. |
| Piston Stroke |
76.8 mm
3.02 in. |
| Compression ratio | 9.8 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Engine oil capacity |
4.2 l
4.44 US qt | 3.7 UK qt |
| Oil viscosity | No Data |
| Coolant |
5 l
5.28 US qt | 4.4 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1150 kg
2535.32 lbs. |
| Max. weight |
1640 kg
3615.58 lbs. |
| Max load |
490 kg
1080.27 lbs. |
| Trunk (boot) space - minimum |
305 l
10.77 cu. ft. |
| Trunk (boot) space - maximum |
1454 l
51.35 cu. ft. |
| Fuel tank capacity |
51 l
13.47 US gal | 11.22 UK gal |
| Max. roof load |
80 kg
176.37 lbs. |
| Permitted trailer load with brakes (12%) |
900 kg
1984.16 lbs. |
| Permitted trailer load without brakes |
550 kg
1212.54 lbs. |
| Permitted towbar download |
75 kg
165.35 lbs. |
| Dimensions |
|---|
| Length |
4034 mm
158.82 in. |
| Width |
1709 mm
67.28 in. |
| Width including mirrors |
1960 mm
77.17 in. |
| Height |
1589 mm
62.56 in. |
| Wheelbase |
2575 mm
101.38 in. |
| Front track |
1472 mm
57.95 in. |
| Rear (Back) track |
1450 mm
57.09 in. |
| Front overhang |
802 mm
31.57 in. |
| Rear overhang |
657 mm
25.87 in. |
| Ride height (ground clearance) |
120 mm
4.72 in. |
| Minimum turning circle (turning diameter) |
10.4 m
34.12 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Semi-independent, coil spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 165/65 R15 |
| Wheel rims size | 15 |
|---|
|
|---|
