| General information |
|---|
| Brand | Mitsubishi |
|---|
| Model | Grandis |
|---|
| Generation | Grandis |
|---|
| Modification (Engine) | 2.0 DI-D (136 Hp) |
|---|
| Start of production | 2005 year |
|---|
| End of production | 2011 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 7 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 10.8 sec |
|---|
| Acceleration 0 - 62 mph | 10.8 sec |
|---|
| Acceleration 0 - 60 mph | 10.3 sec |
|---|
| Maximum speed |
197 km/h
122.41 mph |
| Weight-to-power ratio | 12.8 kg/Hp, 78.2 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.6 kg/Nm, 178.2 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 136 Hp @ 4000 rpm. |
|---|
| Power per litre | 69.1 Hp/l |
|---|
| Torque |
310 Nm @ 1750 rpm.
228.64 lb.-ft. @ 1750 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1968 cm3
120.09 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
81 mm
3.19 in. |
| Piston Stroke |
95.5 mm
3.76 in. |
| Compression ratio | 18 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1740 kg
3836.04 lbs. |
| Max. weight |
2340 kg
5158.82 lbs. |
| Max load |
600 kg
1322.77 lbs. |
| Trunk (boot) space - minimum |
320 l
11.3 cu. ft. |
| Trunk (boot) space - maximum |
1545 l
54.56 cu. ft. |
| Fuel tank capacity |
65 l
17.17 US gal | 14.3 UK gal |
| Dimensions |
|---|
| Length |
4765 mm
187.6 in. |
| Width |
1795 mm
70.67 in. |
| Height |
1655 mm
65.16 in. |
| Wheelbase |
2830 mm
111.42 in. |
| Front track |
1550 mm
61.02 in. |
| Rear (Back) track |
1555 mm
61.22 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Spring Strut |
|---|
| Rear suspension | Transverse stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 215/60 R16 |
|
|---|
