| General information |
|---|
| Brand | Mitsubishi |
|---|
| Model | Carisma |
|---|
| Generation | Carisma Hatchback |
|---|
| Modification (Engine) | 1.6 (90 Hp) |
|---|
| Start of production | 1996 year |
|---|
| End of production | 2000 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Hatchback |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
9.5 l/100 km
24.76 US mpg29.73 UK mpg10.53 km/l |
| Fuel consumption (economy) - extra urban |
6 l/100 km
39.2 US mpg47.08 UK mpg16.67 km/l |
| Fuel consumption (economy) - combined |
8 l/100 km
29.4 US mpg35.31 UK mpg12.5 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12 sec |
|---|
| Acceleration 0 - 62 mph | 12 sec |
|---|
| Acceleration 0 - 60 mph | 11.4 sec |
|---|
| Maximum speed |
180 km/h
111.85 mph |
| Weight-to-power ratio | 12.3 kg/Hp, 81.4 Hp/tonne |
|---|
| Weight-to-torque ratio | 8.1 kg/Nm, 124 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 90 Hp @ 5500 rpm. |
|---|
| Power per litre | 56.4 Hp/l |
|---|
| Torque |
137 Nm @ 4000 rpm.
101.05 lb.-ft. @ 4000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1597 cm3
97.45 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
81 mm
3.19 in. |
| Piston Stroke |
77.5 mm
3.05 in. |
| Compression ratio | 10 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | OHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1105 kg
2436.11 lbs. |
| Max. weight |
1630 kg
3593.53 lbs. |
| Max load |
525 kg
1157.43 lbs. |
| Trunk (boot) space - minimum |
440 l
15.54 cu. ft. |
| Trunk (boot) space - maximum |
660 l
23.31 cu. ft. |
| Fuel tank capacity |
60 l
15.85 US gal | 13.2 UK gal |
| Dimensions |
|---|
| Length |
4450 mm
175.2 in. |
| Width |
1710 mm
67.32 in. |
| Height |
1405 mm
55.31 in. |
| Wheelbase |
2550 mm
100.39 in. |
| Front track |
1455 mm
57.28 in. |
| Rear (Back) track |
1475 mm
58.07 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Spring Strut |
|---|
| Rear suspension | Helical spring |
|---|
| Front brakes | Disc |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 185/65 R14 |
| Wheel rims size | 14 |
|---|
|
|---|
