| General information |
|---|
| Brand | Hyundai |
|---|
| Model | Sonata |
|---|
| Generation | Sonata VI (YF) |
|---|
| Modification (Engine) | 2.0 (165 Hp) |
|---|
| Start of production | 2009 year |
|---|
| End of production | 2012 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
10.8 l/100 km
21.78 US mpg26.16 UK mpg9.26 km/l |
| Fuel consumption (economy) - extra urban |
6.1 l/100 km
38.56 US mpg46.31 UK mpg16.39 km/l |
| Fuel consumption (economy) - combined |
7.8 l/100 km
30.16 US mpg36.22 UK mpg12.82 km/l |
| CO2 emissions | 188 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 9.8 sec |
|---|
| Acceleration 0 - 62 mph | 9.8 sec |
|---|
| Acceleration 0 - 60 mph | 9.3 sec |
|---|
| Maximum speed |
210 km/h
130.49 mph |
| Weight-to-power ratio | 8.5 kg/Hp, 117.3 Hp/tonne |
|---|
| Weight-to-torque ratio | 7.1 kg/Nm, 140.7 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 165 Hp @ 6200 rpm. |
|---|
| Power per litre | 82.6 Hp/l |
|---|
| Torque |
198 Nm @ 4600 rpm.
146.04 lb.-ft. @ 4600 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1998 cm3
121.93 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
86 mm
3.39 in. |
| Piston Stroke |
86 mm
3.39 in. |
| Compression ratio | 10.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC, CVVT |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1407 kg
3101.9 lbs. |
| Max. weight |
1980 kg
4365.15 lbs. |
| Max load |
573 kg
1263.25 lbs. |
| Trunk (boot) space - minimum |
523 l
18.47 cu. ft. |
| Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
| Dimensions |
|---|
| Length |
4820 mm
189.76 in. |
| Width |
1835 mm
72.24 in. |
| Height |
1470 mm
57.87 in. |
| Wheelbase |
2795 mm
110.04 in. |
| Front track |
1597 mm
62.87 in. |
| Rear (Back) track |
1597 mm
62.87 in. |
| Drag coefficient (Cd) | 0.28 |
|---|
| Minimum turning circle (turning diameter) |
10.9 m
35.76 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 205/65 R16 |
| Wheel rims size | 6.5J x 16 |
|---|
|
|---|
