| General information |
|---|
| Brand | Hyundai |
|---|
| Model | Elantra |
|---|
| Generation | Elantra II Wagon |
|---|
| Modification (Engine) | 1.6 16V (114 Hp) |
|---|
| Start of production | 1996 year |
|---|
| End of production | 2000 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Station wagon (estate) |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
10.6 l/100 km
22.19 US mpg26.65 UK mpg9.43 km/l |
| Fuel consumption (economy) - extra urban |
6.7 l/100 km
35.11 US mpg42.16 UK mpg14.93 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 11.2 sec |
|---|
| Acceleration 0 - 62 mph | 11.2 sec |
|---|
| Acceleration 0 - 60 mph | 10.6 sec |
|---|
| Maximum speed |
190 km/h
118.06 mph |
| Weight-to-power ratio | 11.3 kg/Hp, 88.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 9 kg/Nm, 111.5 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 114 Hp @ 6100 rpm. |
|---|
| Power per litre | 71.3 Hp/l |
|---|
| Torque |
143 Nm @ 3000 rpm.
105.47 lb.-ft. @ 3000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1599 cm3
97.58 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
77.4 mm
3.05 in. |
| Piston Stroke |
85 mm
3.35 in. |
| Compression ratio | 9.9 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1283 kg
2828.53 lbs. |
| Max. weight |
1715 kg
3780.93 lbs. |
| Max load |
432 kg
952.4 lbs. |
| Trunk (boot) space - minimum |
362 l
12.78 cu. ft. |
| Trunk (boot) space - maximum |
607 l
21.44 cu. ft. |
| Fuel tank capacity |
55 l
14.53 US gal | 12.1 UK gal |
| Dimensions |
|---|
| Length |
4450 mm
175.2 in. |
| Width |
1700 mm
66.93 in. |
| Height |
1457 mm
57.36 in. |
| Wheelbase |
2550 mm
100.39 in. |
| Front track |
1465 mm
57.68 in. |
| Rear (Back) track |
1450 mm
57.09 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Wishbone |
|---|
| Rear suspension | Spring Strut |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 175/65 R14 |
|
|---|
