General information
BrandFord
Model Expedition
Generation Expedition II
Modification (Engine) 4.6 i V8 16V (235 Hp)
Start of production 2003 year
End of production 2004 year
Powertrain Architecture Internal Combustion engine
Body typeSUV
Seats 8
Doors 5
Performance specs
Fuel consumption (economy) - urban 16.8 l/100 km 14 US mpg16.81 UK mpg5.95 km/l
Fuel consumption (economy) - extra urban 12.4 l/100 km 18.97 US mpg22.78 UK mpg8.06 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h10.3 sec
Acceleration 0 - 62 mph10.3 sec
Acceleration 0 - 60 mph 9.8 sec
Maximum speed 170 km/h 105.63 mph
Weight-to-power ratio 10.4 kg/Hp, 95.7 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 160.5 Nm/tonne
Engine specs
Power 235 Hp @ 4750 rpm.
Power per litre 51.1 Hp/l
Torque 394 Nm @ 3450 rpm. 290.6 lb.-ft. @ 3450 rpm.
Engine location Front, Longitudinal
Engine displacement 4601 cm3 280.77 cu. in.
Number of cylinders 8
Position of cylinders V-engine
Cylinder Bore 90.2 mm 3.55 in.
Piston Stroke 90 mm 3.54 in.
Compression ratio 9.4
Number of valves per cylinder 2
Fuel System Multi-point indirect injection
Engine aspiration Naturally aspirated engine
Space, Volume and weights
Kerb Weight 2455 kg 5412.35 lbs.
Max. weight 3062 kg 6750.55 lbs.
Max load 607 kg 1338.21 lbs.
Trunk (boot) space - minimum 571 l 20.16 cu. ft.
Trunk (boot) space - maximum 1723 l 60.85 cu. ft.
Fuel tank capacity 106 l 28 US gal | 23.32 UK gal
Dimensions
Length 5228 mm 205.83 in.
Width 2000 mm 78.74 in.
Height 1971 mm 77.6 in.
Wheelbase 3023 mm 119.02 in.
Front track 1702 mm 67.01 in.
Rear (Back) track 1709 mm 67.28 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of Gears (automatic transmission) 4
Front suspension Double wishbone
Rear suspension Double wishbone
Front brakesVentilated discs
Rear brakesVentilated discs
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 265/70 R17
