| General information |
|---|
| Brand | Caterham |
|---|
| Model | Seven |
|---|
| Generation | Super |
|---|
| Modification (Engine) | 1.4 i 16V (106 Hp) |
|---|
| Start of production | 1992 year |
|---|
| End of production | 1995 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Cabriolet |
|---|
| Seats | 2 |
|---|
| Doors | 2 |
|---|
| Performance specs |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 6.7 sec |
|---|
| Acceleration 0 - 62 mph | 6.7 sec |
|---|
| Acceleration 0 - 60 mph | 6.4 sec |
|---|
| Maximum speed |
177 km/h
109.98 mph |
| Weight-to-power ratio | 5.1 kg/Hp, 196.3 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.2 kg/Nm, 237 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 106 Hp @ 6000 rpm. |
|---|
| Power per litre | 75.9 Hp/l |
|---|
| Torque |
128 Nm @ 5000 rpm.
94.41 lb.-ft. @ 5000 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine displacement |
1396 cm3
85.19 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
75 mm
2.95 in. |
| Piston Stroke |
79 mm
3.11 in. |
| Compression ratio | 10 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
540 kg
1190.5 lbs. |
| Trunk (boot) space - minimum |
75 l
2.65 cu. ft. |
| Fuel tank capacity |
36 l
9.51 US gal | 7.92 UK gal |
| Dimensions |
|---|
| Length |
3380 mm
133.07 in. |
| Width |
1580 mm
62.2 in. |
| Height |
1120 mm
44.09 in. |
| Wheelbase |
2230 mm
87.8 in. |
| Front track |
1270 mm
50 in. |
| Rear (Back) track |
1330 mm
52.36 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Wishbone |
|---|
| Rear suspension | Suspension De-Dion |
|---|
| Front brakes | Disc |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 185/60 R14 |
| Wheel rims size | 6J X 14 |
|---|
|
|---|
