General information
BrandCadillac
Model Escalade
Generation Escalade IV
Modification (Engine) 6.2 V8 (420 Hp) AWD Automatic
Start of production 2014 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body typeSUV
Seats 7-8
Doors 4
Performance specs
Fuel consumption (economy) - combined 13.1 l/100 km 17.96 US mpg21.56 UK mpg7.63 km/l
CO2 emissions302 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h6.7 sec
Acceleration 0 - 62 mph6.7 sec
Acceleration 0 - 60 mph 6.4 sec
Maximum speed 180 km/h 111.85 mph
Weight-to-power ratio 6.6 kg/Hp, 152.7 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 221.7 Nm/tonne
Engine specs
Power 420 Hp @ 5600 rpm.
Power per litre 68.2 Hp/l
Torque 610 Nm @ 4100 rpm. 449.91 lb.-ft. @ 4100 rpm.
Maximum engine speed 6000 rpm.
Engine location Front, Longitudinal
Engine Model/Code L86
Engine displacement 6162 cm3 376.03 cu. in.
Number of cylinders 8
Position of cylinders V-engine
Cylinder Bore 103.25 mm 4.06 in.
Piston Stroke 92 mm 3.62 in.
Compression ratio 11.5
Number of valves per cylinder 2
Fuel System Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 7.6 l 8.03 US qt | 6.69 UK qt
Oil viscosity No Data
Coolant 16.8 l 17.75 US qt | 14.78 UK qt
Engine systemsStart & Stop System
Space, Volume and weights
Kerb Weight 2751 kg 6064.92 lbs.
Max. weight 3311 kg 7299.51 lbs.
Max load 560 kg 1234.59 lbs.
Trunk (boot) space - minimum 431 l 15.22 cu. ft.
Trunk (boot) space - maximum 2668 l 94.22 cu. ft.
Fuel tank capacity 98 l 25.89 US gal | 21.56 UK gal
Permitted trailer load with brakes (12%) 3100-3000 kg 6834.33 - 6613.87 lbs.
Dimensions
Length 5179 mm 203.9 in.
Width 2044 mm 80.47 in.
Height 1889 mm 74.37 in.
Wheelbase 2946 mm 115.98 in.
Front track 1745 mm 68.7 in.
Rear (Back) track 1744 mm 68.66 in.
Ride height (ground clearance) 205 mm 8.07 in.
Minimum turning circle (turning diameter) 11.9 m 39.04 ft.
Approach angle 15.7°
Departure angle 23.1°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) permanently drives the four wheels of the vehicle.
Drive wheel All wheel drive (4x4)
Number of Gears (automatic transmission) 6
Front suspension Double wishbone
Rear suspension Multi-link independent
Front brakesVentilated discs
Rear brakesVentilated discs
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 285/45 R22
Wheel rims size9.0J x 22
