General information
BrandBMW
Model 5 Series
Generation 5 Series Active Hybrid (F10H LCI, facelift 2013)
Modification (Engine) ActiveHybrid 3.0 (340 Hp)
Start of production 2013 year
End of production 2016 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body typeSedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) - urban 6.1-6.7 l/100 km 38.56 - 35.11 US mpg46.31 - 42.16 UK mpg16.39 - 14.93 km/l
Fuel consumption (economy) - extra urban 6.6-7.2 l/100 km 35.64 - 32.67 US mpg42.8 - 39.23 UK mpg15.15 - 13.89 km/l
Fuel consumption (economy) - combined 6.4-7.0 l/100 km 36.75 - 33.6 US mpg44.14 - 40.35 UK mpg15.63 - 14.29 km/l
CO2 emissions149-163 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h5.9 sec
Acceleration 0 - 62 mph5.9 sec
Acceleration 0 - 60 mph 5.6 sec
Maximum speed 250 km/h 155.34 mph
Emission standard Euro 6
Weight-to-power ratio 5.4 kg/Hp, 183.8 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 216.2 Nm/tonne
Engine specs
Power 340 Hp @ 5800-6400 rpm.
Power per litre 114.1 Hp/l
Torque 400 Nm @ 1200-5000 rpm. 295.02 lb.-ft. @ 1200-5000 rpm.
Engine location Front, Longitudinal
Engine Model/Code N55B30A
Engine displacement 2979 cm3 181.79 cu. in.
Number of cylinders 6
Position of cylinders Inline
Cylinder Bore 84 mm 3.31 in.
Piston Stroke 89.6 mm 3.53 in.
Compression ratio 10.2
Number of valves per cylinder 4
Fuel System Direct injection
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 6.5 l 6.87 US qt | 5.72 UK qt
Oil viscosity No Data
Engine oil specification
Coolant 9-9.3 l 9.51 - 9.83 US qt | 7.92 - 8.18 UK qt
Space, Volume and weights
Kerb Weight 1850 kg 4078.55 lbs.
Max. weight 2400 kg 5291.09 lbs.
Max load 550 kg 1212.54 lbs.
Trunk (boot) space - minimum 375 l 13.24 cu. ft.
Fuel tank capacity 67 l 17.7 US gal | 14.74 UK gal
Max. roof load 100 kg 220.46 lbs.
Dimensions
Length 4907 mm 193.19 in.
Width 1860 mm 73.23 in.
Height 1464 mm 57.64 in.
Wheelbase 2968 mm 116.85 in.
Front track 1600 mm 62.99 in.
Rear (Back) track 1627 mm 64.06 in.
Ride height (ground clearance) 141 mm 5.55 in.
Drag coefficient (Cd) 0.27
Minimum turning circle (turning diameter) 12.0 m 39.37 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel Rear wheel drive
Number of Gears (automatic transmission) 8 Steptronic
Front suspension Double wishbone
Rear suspension Multi-link independent
Front brakesVentilated discs
Rear brakesVentilated discs
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20
Wheel rims size8J x 17; 8J x 18; 9J x 18; 8.5J x 19; 9J x 19; 8.5J x 20; 9J x 20
