| General information |
|---|
| Brand | Audi |
|---|
| Model | S5 |
|---|
| Generation | S5 Sportback (F5, facelift 2019) |
|---|
| Modification (Engine) | 3.0 TDI V6 (347 Hp) MHEV quattro Tiptronic |
|---|
| Start of production | December, 2019 year |
|---|
| Powertrain Architecture | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
|---|
| Body type | Fastback |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
7.2 l/100 km
32.67 US mpg39.23 UK mpg13.89 km/l |
| Fuel consumption (economy) - extra urban |
5.5-5.6 l/100 km
42.77 - 42 US mpg51.36 - 50.44 UK mpg18.18 - 17.86 km/l |
| Fuel consumption (economy) - combined |
6.1-6.2 l/100 km
38.56 - 37.94 US mpg46.31 - 45.56 UK mpg16.39 - 16.13 km/l |
| CO2 emissions | 160-162 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 4.9 sec |
|---|
| Acceleration 0 - 62 mph | 4.9 sec |
|---|
| Acceleration 0 - 60 mph | 4.7 sec |
|---|
| Maximum speed |
250 km/h
155.34 mph |
| Emission standard | Euro 6 |
|---|
| Weight-to-power ratio | 5.2 kg/Hp, 192.2 Hp/tonne |
|---|
| Weight-to-torque ratio | 2.6 kg/Nm, 387.8 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 347 Hp @ 3850 rpm. |
|---|
| Power per litre | 117 Hp/l |
|---|
| Torque |
700 Nm @ 2500-3100 rpm.
516.29 lb.-ft. @ 2500-3100 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | DEWB |
|---|
| Engine displacement |
2967 cm3
181.06 cu. in. |
| Number of cylinders | 6 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
83 mm
3.27 in. |
| Piston Stroke |
91.4 mm
3.6 in. |
| Compression ratio | 15.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Engine oil capacity |
6.1 l
6.45 US qt | 5.37 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
10 l
10.57 US qt | 8.8 UK qt |
| Engine systems | Start & Stop SystemParticulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1805 kg
3979.34 lbs. |
| Max. weight |
2380 kg
5247 lbs. |
| Max load |
575 kg
1267.66 lbs. |
| Trunk (boot) space - minimum |
430 l
15.19 cu. ft. |
| Fuel tank capacity |
58 l
15.32 US gal | 12.76 UK gal |
| AdBlue tank |
12 l
3.17 US gal | 2.64 UK gal |
| Max. roof load |
90 kg
198.42 lbs. |
| Permitted trailer load with brakes (8%) |
2100 kg
4629.71 lbs. |
| Permitted trailer load with brakes (12%) |
1900 kg
4188.78 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
80 kg
176.37 lbs. |
| Dimensions |
|---|
| Length |
4757 mm
187.28 in. |
| Width |
1843 mm
72.56 in. |
| Width including mirrors |
2029 mm
79.88 in. |
| Height |
1395 mm
54.92 in. |
| Wheelbase |
2825 mm
111.22 in. |
| Front track |
1587 mm
62.48 in. |
| Rear (Back) track |
1568 mm
61.73 in. |
| Drag coefficient (Cd) | 0.29 |
|---|
| Minimum turning circle (turning diameter) |
11.7 m
38.39 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode. |
|---|
| Drive wheel | All wheel drive (4x4) |
|---|
| Number of Gears (automatic transmission) | 8 Tiptronic |
|---|
| Front suspension | Multi-link suspension |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 245/40 R18 97 Y XL |
| Wheel rims size | 8.5J x 18 |
|---|
|
|---|
